Ricoh MP C2504 - TM;ID Sensor

To Next Page

To Previous Page

TM/ID Sensor

[A]: TM/ID sensor (front)

[B]: TM/ID sensor (center)

[C]: TM/ID sensor (rear)

[A]: Paper transfer roller (standard roller)

[B]: Paper transfer roller (Imageable Area Extension Unit Type M19)

When Imageable Area Extension Unit (316mm) is equipped, 316mm width printing is done instead of

Real Time Process Control at margin.

7. Detailed Descriptions

1158
