Items MP C2003/C2503/C2011 MP C2004/C2504
Normal Operation
rough adjustment -> fine
adjustment only
rough adjustment -> fine adjustment ->
contact MUSIC
With Imageable
Area Extension Unit
rough adjustment -> fine
adjustment only
rough adjustment -> fine
* Same as the previous machine
Execution time varies from model to model.
Items MP C2003/C2503/C2011 MP C2004/C2504
Execution time About 22 sec. About 29 sec.
MUSIC Error Judgment
When MUSIC is done, the results must be checked for each color. SP2-194-007 shows whether
MUSIC was OK or NG, and SP2-194-010 to 012 show the details of the result.
• SP2-194-007 (Execution Result)
Detection Result Meaning
0 Success
1 Failure
• SP2-194-010 (Error Result: C)
• SP2-194-011 (Error Result: M)
• SP2-194-012 (Error Result: Y)
Detection Result Meaning
0 MUSIC not executed
1
Correction Succeeded: Sampling is conducted correctly and the correction is
completed
2 Sampling Failed (When the MUSIC pattern failed to be detected)
3
Detection Patterns Lack (When the number of lines detected is smaller than the
fixed number)
4
The sampled data is beyond the correction range.
(Calculated correction value is just out of rage)
Process Control
1129
