Paper Feed Unit PB3150 (D694)
Accessory Check
No. Descriptions Q’ty Remarks
1 Securing Bracket 2
2 Screws - M4 × 10 2
3 Screw with Spring Washer - M4 × 10 1
Installation Procedure
• The main machine weighs approximately 100 kg. Make sure to lift it with the help of at least one
more person.
• The machine should be held at the correct locations and lifted gently by two people. If it is lifted
without care, handled carelessly or dropped, it may result in injury.
• When installing this option, turn OFF the main power and unplug the power cord from the wall
socket. If installing without turning OFF the main power, an electric shock or a malfunction may
occur.
• Be sure to join the machine to the paper feed unit so as to prevent equipment from falling over. If
they are not connected, they may move and fall over, resulting in injury.
Paper Feed Unit PB3150 (D694)
135
