Camera Direct Print Card Type M19 (D3BD-13)

Accessory Check

No. Description Q’ty

1 SD Card 1

Installation Procedure

• When installing more than one SD card, perform the merge operation (page 347 "SD Card Appli

Move").

1. Remove the SD card slot cover [A].

2. Installation

354
