8. Move the movable tray [A] up and down to check that the Mylar does go through the
sensor properly.
9. Re-attach the left lower cover ( x2)
10. Re-attach the finisher front cover ( x2)
Paper Curl Problem for SR3180 (D766)
When using the mixed mode, duplex (curls towards the lower side) over the simplex (curl towards the
upper side) and paper curl occurs, attach the auxiliary tray (D7667010), disable the paper exit full
sensor, and paste the Mylar.
Troubleshooting for Finishing Options
1051

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
