Ricoh MP C2504 - Laser Unit; Decal Location

Laser Unit
• Turn off the main power switch and unplug the machine before beginning any of the procedures in
this section. Laser beams can cause serious eye injury.
• Caution Decals
• Decal Location
Laser Unit
• A polygon mirror motor protection bracket and a red tag are attached to each new laser unit.
Remove these before you install the new unit.
4. Replacement and Adjustment
452
