Installation Procedure
• When installing this option, turn OFF the main power and unplug the power cord from the wall
socket. If installing without turning OFF the main power, an electric shock or a malfunction may
occur.
• This option cannot be used together with the following peripherals:
- Internal Shift Tray SH3070 (D691)
- Side Tray Type M3 (D725)
- Internal Finisher SR 3180 (D766)
- Bridge Unit BU3070 (D685)
• To use together with the "1 Bin Tray BN3110 (D3CQ)", after attaching the bottom plate of this
option, attach the "1 Bin Tray BN3110 (D3CQ)", and then install this option.
• To use together with the "Punch Unit PU3040 (D716)", first attach the "Punch Unit PU3040
(D716)" before installing this option.
1. Remove the orange tapes and shipping retainers.
2. Remove the package accessories (fixing screws, etc.).
2. Installation
220
