[G]: Replacing the USB cable and the operation panel

1. Remove the Platen Cover, or ARDF/SPDF. (page 429)

2. Remove a screw at the scanner right cover.

3. Remove the scanner right cover [A]

Remove the hook at the upper part, and then slide the cover in the rear direction.
