Ricoh MP C2504 - Firmware Update (Remote Firmware Update); RFU Performable Condition; Types of Firmware Update Files, Supported Update Methods

To Next Page

To Previous Page

Firmware Update (Remote Firmware Update)

In this machine, software can be updated by remote control using @Remote.

Types of firmware update files, supported update methods:

SFU SD RFU ARFU

Individual firmware N/A Available Available N/A

Package firmware Available Available Available Available

RFU Performable Condition

RFU is performable for a device which meets the following conditions.

1. The customer consents to the use of RFU.

2. The device is connected to a network via TCP/IP for @Remote.

5. System Maintenance

686
