Ricoh MP C2504 - Right and Left Side Covers

To Next Page

To Previous Page

No. Cover name

4 Main power switch cover

5 Rear cover

6 Rear lower cover

Right and Left Side Covers

No. Cover name

1 Right upper cover

2 Right door

3 Right rear cover

4 Left rear cover

5 Controller cover

6 Left cover

7 Upper left cover

Exterior Covers

403
