• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
Target Part/SP No.: Duplex Exit Sensor / SP5-803-010
Cause verification Problem Judgement
Execute an INPUT check when there is no paper at the position of the
referenced sensor.
0: Paper detected
Execute an INPUT check when there is paper at the position of the
referenced sensor.
1: Paper not detected
Solution:
• Clean the sensor.
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
Jam
If the error occurs periodically, do the following steps. If the result is as shown in the "Problem
Judgement" column, follow the solutions.
Bypass No Feeding: Cause Code 008
Target Part/SP No.:Bypass/Duplex motor / SP5-804-071 (Duplex Bypass Motor: CW:
Standard Speed)
Cause verification Problem Judgement
Turn the referenced motor OFF with OUTPUT Drive sound heard
Turn the referenced motor ON with OUTPUT Drive sound not heard
Solution:
• Reconnect the connector.
• Replace the motor.
6. Troubleshooting
1012
