NFC Card Reader Type M19 (D3BS-21)

Accessory Check

No. Description Q'ty Remarks

1 Corner Cover 1

2 Reader Spacer 1

3 Reader Cover 1

4 Reader 1

5 Sponge Cushions 2

6 Ferrite Core (Black) 1

7 Interface Cable 1

NFC Card Reader Type M19 (D3BS-21)
