Ricoh MP C2504 - Ways to Fix Color Registration Errors

followed by the center and then the left. For "C" or "Y", the order will be reversed. This is because
the writing direction of the laser beam for "K" and "M" is different from "C" and "Y".
Case "M"
Case "C" or "Y"
5. Pattern 5
This is a case in which a color registration error is found in the sub-scan direction, but it is not the
same as the Pattern 1 or 2. The error appears and disappears at intervals down the page.
Ways to fix color registration errors
SP2-111-004 (Forced Line Position Adj. : Mode D) Execution
Result: Failed Case: SP2-194-007: 1 (Failed)
4. Replacement and Adjustment
656
