Md. From To Distance
Two-way
distribution
Fusing roller (nip) Reverse roller 143.6
Reverse roller Duplex entrance roller 1 131.3
Duplex re-supply
Duplex entrance roller 1 Duplex entrance roller 2 120.4
Duplex entrance roller 2 Duplex transport roller 90.9
Duplex transport roller Duplex exit roller 110.2
Duplex exit roller Registration roller 94.7
Bypass feed
Bypass pick-up roller Bypass paper feed roller 30.0
Bypass paper feed roller Bypass transport roller 24.5
Bypass transport roller First transport roller 56.0
Sensor Position
Distance units: mm
Md. From To Distance
1st tray paper
feed
Transport roller 1 Transport sensor 1 16.8
2nd tray paper
feed
Transport roller 2 Transport sensor 2 24.3
Transport sensor 2 Transport sensor 1 88.7
Registration Registration sensor Registration roller 17.2
Paper exit Paper exit sensor Paper exit roller 17.0
Two-way
distribution
Reverse roller Reverse sensor 14.0
Duplex
Duplex entrance roller Duplex entrance sensor 25.0
Duplex exit roller Duplex exit sensor 15.0
1-bin Reverse sensor 1-bin paper exit roller -
Paper Feed/ Transport Section
1183

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
