3. Attach the studs provided with the option on the helmholtz silencer (Stud ×4).

4. Attach the counter interface board [A].

5. Connect the harness [A] of the MFP to the white connector (13 pins) [B].

• Do not use the harness that is provided with the accessories for the interface cable.

• Connect the harness of the optional counter to the black connector [C].

2. Installation

310
