Ricoh MP C2504 User Manual

8. Repeat steps 1 to 7 until all the ACC test patterns have been printed.
2. Exit the User Tools mode.
3. Press the “Document Server” icon.
Or press and hold the [A] key and "Check Status [B]" at the same time until the number
keyboard screen is displayed.
4. Enter the key code for SP mode.
5. Perform line adjustment.
1. Execute SP2-111-004 (Forced Line Position Adj. Mode d)
2. The result can be checked with SP2-194-007 (MUSIC Execution Result)
0: Success, 1: Failure
2. Installation
80

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
