6-161-040 Fold Cam HP Sensor ENG [0 or 1 / 0 / 1/step]
6-161-041 TE Stopper Transport Sensor ENG [0 or 1 / 0 / 1/step]
6-161-042 TE Stopper HP Sensor ENG [0 or 1 / 0 / 1/step]
6-161-043 Booklet Folder Exit Sensor ENG [0 or 1 / 0 / 1/step]
6-161-044 Booklet Folder Tray Full Sensor:
Upper
ENG [0 or 1 / 0 / 1/step]
6-161-045 Booklet Folder Tray Full Sensor:
Lower
ENG [0 or 1 / 0 / 1/step]
6161 [FIN (1K FIN) INPUT Check]
Gets information of specified switch. Displays signal level of switch as it is.
6-161-046 Door Open/Close SW ENG [0 or 1 / 0 / 1/step]
6-161-047 Lift Tray Upper Limit SW ENG [0 or 1 / 0 / 1/step]
6161 [FIN (1K FIN) INPUT Check]
Gets information of specified sensor. Displays signal level of sensor as it is.
6-161-048 Paper Guide HP Sensor ENG [0 or 1 / 0 / 1/step]
6184 [Input Check: NoStplBindFIN]
6-184-001 Entrance Sensor ENG [0 or 1 / 0 / 1/step]
Gets the entrance sensor information of non staple finisher.
(0: Sensor Off, 1: Sensor On)
6-184-002 Exit Sensor ENG [0 or 1 / 0 / 1/step]
Gets the paper exit sensor information of non staple finisher.
(0: Sensor Off, 1: Sensor On)
6-184-003 Horizontal Registration Detection
Sensor
ENG [0 or 1 / 0 / 1/step]
Gets the horizontal registration sensor information of non staple finisher.
(0: Sensor Off, 1: Sensor On)
3. Engine SP Mode Tables
474
