6-161-020 Clincher HP Sensor (Corner/
Booklet Stapler)
ENG [0 or 1 / 0 / 1/step]
6-161-022 Stapler Retraction Sensor ENG [0 or 1 / 0 / 1/step]
6-161-023 Untitled ENG [0 or 1 / 0 / 1/step]
6-161-024 Untitled ENG [0 or 1 / 0 / 1/step]
6-161-025 Untitled ENG [0 or 1 / 0 / 1/step]
6-161-026 Punch HP Sensor ENG [0 or 1 / 0 / 1/step]
6-161-027 Punch RP Sensor ENG [0 or 1 / 0 / 1/step]
6-161-028 Punch Hopper Full Sensor ENG [0 or 1 / 0 / 1/step]
6-161-029 Punch Move HP Sensor ENG [0 or 1 / 0 / 1/step]
6-161-030 S-to-S Registration Detection HP
Sensor
ENG [0 or 1 / 0 / 1/step]
6-161-031 S-to-S Registration Detection
Sensor
ENG [0 or 1 / 0 / 1/step]
6161 [FIN (1K FIN) INPUT Check]
Gets information of specified switch. Displays signal level of switch as it is.
6-161-032 Punch Selection DIPSW 1 ENG [0 or 1 / 0 / 1/step]
6-161-033 Punch Selection DIPSW 2 ENG [0 or 1 / 0 / 1/step]
6161 [FIN (1K FIN) INPUT Check]
Gets information of specified sensor. Displays signal level of sensor as it is.
6-161-034 ITB Transport Sensor: Right ENG [0 or 1 / 0 / 1/step]
6-161-035 ITB Transport Sensor: Left ENG [0 or 1 / 0 / 1/step]
6-161-036 Stack Transport Sensor ENG [0 or 1 / 0 / 1/step]
6-161-037 Stack Trans Upper Pressure
Release HP Sensor
ENG [0 or 1 / 0 / 1/step]
6-161-038 Stack Trans Lower Pressure
Release HP Sensor
ENG [0 or 1 / 0 / 1/step]
6-161-039 Fold Blade HP Sensor ENG [0 or 1 / 0 / 1/step]
Input and Output Check
