Ricoh MP C2504 - Page 1707

6161 [FIN (1K FIN) INPUT Check]
Gets information of specified sensor. Displays signal level of sensor as it is.
6-161-001 Entrance Sensor ENG [0 or 1 / 0 / 1/step]
6-161-002 Upper Cover Open/Close
Sensor
ENG [0 or 1 / 0 / 1/step]
6-161-003 Proof Tray Exit Sensor ENG [0 or 1 / 0 / 1/step]
6-161-004 Proof Tray Full Sensor ENG [0 or 1 / 0 / 1/step]
6-161-005 Shift HP Sensor ENG [0 or 1 / 0 / 1/step]
6-161-006 Exit Guide Plate Open/Close HP
Sensor
ENG [0 or 1 / 0 / 1/step]
6-161-007 Shift Paper Exit (Lift Tray Exit)
Sensor
ENG [0 or 1 / 0 / 1/step]
6-161-008 Positioning Roller HP Sensor ENG [0 or 1 / 0 / 1/step]
6-161-009 Lift Tray Paper Sensor ENG [0 or 1 / 0 / 1/step]
6-161-010 Jogger HP Sensor ENG [0 or 1 / 0 / 1/step]
6-161-011 Feed Out HP Sensor ENG [0 or 1 / 0 / 1/step]
6-161-012 Lift Tray Lower Limit Sensor
(Upper)
ENG [0 or 1 / 0 / 1/step]
6-161-013 Lift Tray Lower Limit Sensor
(Lower)
ENG [0 or 1 / 0 / 1/step]
6-161-014 Staple Tray Paper Sensor ENG [0 or 1 / 0 / 1/step]
6-161-015 Stapler Moving HP Sensor ENG [0 or 1 / 0 / 1/step]
6-161-016 Near End Sensor (Common:
Corner/Bklt Stplr)
ENG [0 or 1 / 0 / 1/step]
6-161-017 Self Priming Sensor
(Common:Crnr/Bklt Stplr)
ENG [0 or 1 / 0 / 1/step]
6-161-018 Driver HP Sensor (Corner/
Booklet Stapler)
ENG [0 or 1 / 0 / 1/step]
3. Engine SP Mode Tables
472
