6-135-004 Staple Tray Paper Sensor *ENG [0 or 1 / 0 / 1/step]
6-135-005 Front Jogger HP Sensor *ENG [0 or 1 / 0 / 1/step]
6-135-006 Rear Jogger HP Sensor *ENG [0 or 1 / 0 / 1/step]
6-135-007 Sft Roller HP Sensor *ENG [0 or 1 / 0 / 1/step]
6-135-008 Hitroll HP Sensor *ENG [0 or 1 / 0 / 1/step]
6-135-009 Ext Guide Plate HP Sensor *ENG [0 or 1 / 0 / 1/step]
6-135-010 Staple Moving HP Sensor ENG [0 or 1 / 0 / 1/step]
6-135-011 Shift Tray Paper Sensor ENG [0 or 1 / 0 / 1/step]
6-135-012 Shift Tray Limit Sensor ENG [0 or 1 / 0 / 1/step]
6-135-013 Staple Rotation Sensor ENG [0 or 1 / 0 / 1/step]
6-135-014 Staple Near End Sensor ENG [0 or 1 / 0 / 1/step]
6-135-015 Self Priming Sensor ENG [0 or 1 / 0 / 1/step]
6-135-016 Stopper HP Sensor ENG [0 or 1 / 0 / 1/step]
6-135-017 Punch HP Sensor ENG [0 or 1 / 0 / 1/step]
6-135-018 Punch Pluse Count Sensor ENG [0 or 1 / 0 / 1/step]
6-135-019 Punch Chad Full Sensor ENG [0 or 1 / 0 / 1/step]
6-135-020 Punch Moving HP Sensor ENG [0 or 1 / 0 / 1/step]
6-135-021 Punch Registration Detection HP
Sensor
ENG [0 or 1 / 0 / 1/step]
6-135-022 Punch Registration Detection
Sensor
ENG [0 or 1 / 0 / 1/step]
6135 [INPUT Check: FrontFIN]
Gets information of specified switch. Displays signal level of switch as it is.
6-135-023 Slide Door SW ENG [0 or 1 / 0 / 1/step]
6-135-024 Shift Tray Upper Limit SW ENG [0 or 1 / 0 / 1/step]
Input and Output Check
471
