5-804-001 Feed Pickup Solenoid 1
This setting is not available for
MP C2004/MP C2504.
ENG [0 or 1 / 0 / 1/step]
Moves 1st paper feed tray pick up solenoid.
5-804-002 Feed Pickup Solenoid 2
This setting is not available for
MP C2004/MP C2504.
ENG [0 or 1 / 0 / 1/step]
Moves 2nd paper feed tray pick up solenoid.
5-804-003 Bypass Pickup Solenoid ENG [0 or 1 / 0 / 1/step]
Moves bypass pick up solenoid.
5-804-004 Exit Junction Solenoid ENG [0 or 1 / 0 / 1/step]
Moves output paper divide solenoid.
5804 [OUTPUT Check]
Moves paper feed tray rising motor.
* Do not execute SP 5-804-006/008 without removing the paper tray. Otherwise,
the tray might be damaged.
5-804-005 Tray 1 Lift Motor:CW ENG [0 or 1 / 0 / 1/step]
5-804-006 Tray 1 Lift Motor:CCW ENG
5-804-007 Tray 2 Lift Motor:CW ENG
5-804-008 Tray 2 Lift Motor:CCW ENG
5804 [OUTPUT Check]
Moves register motor.
5-804-009 Regist Motor:CCW:Standard
Speed
ENG [0 or 1 / 0 / 1/step]
5-804-011 Regist Motor:CCW:Low Speed ENG
5804 [OUTPUT Check]
3. Engine SP Mode Tables
476
