Ricoh MP C2504 User Manual

5-804-015 Regist Motor:Position Hold ENG [0 or 1 / 0 / 1/step]
Holds position of register motor.
5804 [OUTPUT Check]
Moves paper feed motor.
* It is fed if there is paper in the paper tray.
5-804-016 Feed Motor:CW:Standard
Speed
ENG [0 or 1 / 0 / 1/step]
5-804-018 Feed Motor:CW:Low Speed ENG
5-804-022 Feed Motor:CCW:Standard
Speed
ENG
5-804-024 Feed Motor:CCW:Low Speed ENG
5804 [OUTPUT Check]
Moves transport motor.
5-804-028 Bypass V-Transport
Motor:CW:Std Speed
ENG [0 or 1 / 0 / 1/step]
5-804-030 Bypass V-Transport
Motor:CW:Low Speed
ENG
5804 [OUTPUT Check]
5-804-034 Bypass V-Transport
Motor:Position Hold
ENG [0 or 1 / 0 / 1/step]
Holds position of transport motor.
5-804-037 Exit Motor: CW: Fusing
Pressure Release
ENG [0 or 1 / 0 / 1/step]
Moves fusing dis-pressure.
* If driving this motor while attaching the fusing unit, be sure to stop it less than 5
seconds. Otherwise, the unit might be damaged.
5804 [OUTPUT Check]
Moves paper exit motor.
Input and Output Check
477

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
