5-804-041 Exit Motor:CCW:Standard
Speed
ENG [0 or 1 / 0 / 1/step]
5-804-043 Exit Motor:CCW:Low Speed ENG
5804 [OUTPUT Check]
Moves reverse motor.
5-804-047 Inverter Motor:CW:Standard
Speed
ENG [0 or 1 / 0 / 1/step]
5-804-049 Inverter Motor:CW:Low Speed ENG
5-804-052 Inverter Mt: CW: Normal
Speed: Duplex
ENG
5-804-054 Inverter Mt: CW: Low Speed:
Duplex
ENG
5-804-056 Inverter Motor:CCW:Standard
Speed
ENG
5-804-058 Inverter Motor:CCW:Low
Speed
ENG
5-804-061 Inverter Mt: CCW: Normal
Speed: Inc Speed
ENG
5804 [OUTPUT Check]
Moves duplex entrance motor.
5-804-065 Duplex Entrance
Motor:CW:Standard Speed
ENG [0 or 1 / 0 / 1/step]
5-804-067 Duplex Entrance
Motor:CW:Low Speed
ENG
5-804-068 Duplex Entrance Motor:
Normal Speed: Duplex
ENG
5-804-069 Duplex Entrance Motor: Low
Speed: Duplex
ENG
5804 [OUTPUT Check]
Moves bypass/duplex motor.
3. Engine SP Mode Tables
478
