5-804-071 Duplex Bypass
Motor:CW:Standard Speed
ENG [0 or 1 / 0 / 1/step]
5-804-073 Duplex Bypass Motor:CW:Low
Speed
ENG
5-804-074 Duplex Bypass Motor: CW:
Normal Speed: Dup
ENG
5-804-075 Duplex Bypass Motor: CW:
Low Speed: Duplex
ENG
5-804-077 Duplex Bypass
Motor:CCW:Standard Speed
ENG
5-804-079 Duplex Bypass
Motor:CCW:Low Speed
ENG
5804 [OUTPUT Check]
5-804-083 Duplex Bypass Motor:Position
Hold
ENG [0 or 1 / 0 / 1/step]
Holds position of bypass/duplex motor.
5804 [OUTPUT Check]
Moves fusing motor. *See Important below
5-804-092 Fusing Motor:CW:Standard
Speed
ENG [0 or 1 / 0 / 1/step]
5-804-094 Fusing Motor:CW:Low Speed ENG
5-804-098 Fusing Motor:CCW:Low Speed ENG
Input and Output Check
479
