[A]: Before setting

[B]: After setting

[C]: Toner path

No. Description No. Description

1 Toner bottle 7 Transport nozzle

2 Coil spring 8 Coil spring

3 Shutter holder 9 Toner transport coil

4 Seal 10 Drive gear

5 Shutter 11 Rocking spring

Toner Supply

1141
