Tray 2, Paper Feed Unit PB3220/PB3210 (D787), and Paper Feed Unit PB3150 (D694) are also

changed from L-shaped sheet metal to support component.

Factory Default:

• Tray 2: A3 (11 inches for NA only)

• Optional Paper Tray: A3 for all regions
