No. Description No. Description
6 Fusing exit guide plate 13 Fusing entrance guide plate
7 Fusing exit roller (driven)
No. Description No. Description
1 Thermopile (edge) 6 Non-contact thermistor (center)
2 Thermopile (center) 7 Pressure roller thermistor (center)
3 Fusing lamp 8 Non-contact thermistor (edge)
4 Fusing sleeve thermostat (edge) 9 Pressure roller thermistor (edge)
5 Fusing sleeve thermostat (center) 10 Pressure roller thermistor (Full-bleed edge)
7. Detailed Descriptions
1188
