Ricoh MP C2504

5-803-015 Tray 1: Paper End Detection ENG [0 or 1 / 0 / 1/step]
0: No paper
1: paper remaining
Detects paper is running out on 1st paper feed tray.
(0: No paper, 1: paper remaining)
5-803-016 Tray 1: Set Sensor ENG [0 or 1 / 0 / 1/step]
0: set
1:not set
Detects that 1st paper feed tray is set to main unit.
(0: set, 1:not set)
5-803-017 Tray 2: Paper Height Sensor ENG [0 to 3 / 0 / 1/step]
When full is 100%,
11: 71 to 100%
01: 31 to 70%
00: 11 to 30%
10: 1 to 10%
Detects remaining paper amount of 2nd paper feed tray.
(When full is 100%,
11: 71 to 100%, 01: 31 to 70%, 00: 11 to 30%, 10: 1 to 10%)
*Check SP5-803-019 for paper end.
5-803-018 Tray 2: Paper End Sensor ENG [0 or 1 / 0 / 1/step]
0: less then limit
1: high then limit
Detects the height of paper loaded in 2nd paper feed tray.
(0: less then limit, 1: high then limit)
* As long as you do not press the white bar of the machine side in the tray back, not
output.
Input and Output Check
451
