5-803-026 Right Door Open/Close Sensor ENG [0 or 1 / 0 / 1/step]
0: close
1: open
Detects right door status.
(0: close, 1: open)
5-803-027 Duplex Guide Plate Open/
Close Sensor
ENG [0 or 1 / 0 / 1/step]
0: close
1: open
Detects duplex guide plate status.
(0: close, 1: open)
5-803-028 PTR Open/Close Sensor ENG [0 or 1 / 0 / 1/step]
0: open
1: close
Detects paper transfer unit status.
(0: open, 1: close)
5-803-029 ITB Contact Sensor ENG [0 or 1 / 0 / 1/step]
0: Abutting
1: Alienate
Detects image transfer roller (Y, M, and C) and photoreceptors distance.
(0: Abutting, 1: Alienate)
5-803-030 PTR Contact Sensor ENG [0 or 1 / 0 / 1/step]
0: Abutting
1: Alienate
Detects image transfer belt and paper transfer rollers distance.
(0: Abutting, 1: Alienate)
5-803-031 New ITB Unit Detection ENG [0 or 1 / 0 / 1/step]
Not available with C1
Input and Output Check
453
