5-803-085 Shift Tray: Position Sensor 1 ENG [0 or 1 / 0 / 1/step]
0: Stop on this side. during moving
towards inner
1: Stop on inner side. during moving
towards this side
Detects shift tray position.
(0: Stop on this side. during moving towards inner,
1: Stop on inner side. during moving towards this side)
5-803-086 Shift Tray: Position Sensor 2 ENG [0 or 1 / 0 / 1/step]
*It is a backup sensor with this machine, so "1" is always displayed)
5-803-094 GAVD Open/Close Detection ENG [0 or 1 / 0 / 1/step]
For checking door open/close during process. No need to operate.
5-803-095 Bridge 24V Fuse Detection ENG [0 or 1 / 0 / 1/step]
0: Not cut
1: Cut
Detects state of 24V fuse on the bridge unit.
(0: Not cut, 1: Cut)
5-803-096 Bridge 5V Fuse Detection ENG [0 or 1 / 0 / 1/step]
0: Not cut
1: Cut
Detects state of 5V fuse on the bridge unit.
(0: Not cut, 1: Cut)
5-803-200 HP Sensor ENG [0 or 1 / 0 / 1/step]
Tests the scanner HP sensor.
5-803-201 Platen Cover Sensor ENG [0 or 1 / 0 / 1/step]
Tests the book open/close sensor.
5803 [INPUT Check]
Gets information of specified sensor.
Input and Output Check
461

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
