16. Remove the connector cover [A].
17. Remove the paper exit lower cover [A].
• The lower inside cover can be removed together with the paper exit lower cover, since the
inside cover is secured on the paper exit lower cover with two screws.
Internal Finisher SR3180 (D766)
249
