7. Tuck in the banner paper guide tray [A].

• The double-sided adhesive tapes stick firmly in about one day.

• When replacing the parts of the Banner Paper Guide Tray, use the installation procedure above in

reverse order as a reference in order to make it easier to disassemble the unit.

2. Installation

264
