1. Remove the SD card slot cover [A].
2. Insert the OCR Unit SD card in SD card slot 1 [A: Upper Slot].
3. Turn ON the main power.
4. Enter the SP mode, and then press "Enter" in SP5-878-004 (Option Setup: OCR
Dictionary).
The SD card ID is saved in the NVRAM, and the ID of the MFP is saved on the SD card. The MFP
and SD card are thereby linked.
5. When "operation complete" is displayed, press "Close".
• If installation fails, "Failed" is displayed.
• If installation fails, perform the following steps.
1. Check whether it is a used SD card.
2. Switch the power OFF, and repeat steps 1-5.
6. Turn the machine OFF and back ON again.
7. Press "Enter" in SP5-878-004 (Option Setup: OCR Dictionary).
Dictionary data is copied to the HDD.
• On the first run, SP5-878-004 links the SD card, and on the second run, copies dictionary
data.
OCR Unit Type M13 (D3AC-23, -24, -25)
359
