Ricoh MP C2504 - Page 48

To Next Page

To Previous Page

No. Description No. Description

1 Platen Cover PN2000 4 Side Tray Type M3

2 Paper Feed Unit PB3150 5 1 Bin Tray BN3110

3 Caster Table Type M3
