No. Description No. Description
5 Paper transfer contact and release motor 16 Toner supply motor (M)
6 Fusing motor 17 Toner supply motor (C)
7 Paper exit /Pressure release motor 18 Toner supply motor (Bk)
8 Duplex entrance motor 19 Development motor: CMY
9 Reverse motor 20 PCU Motor: CMY
10 Toner bottle drive motor (Bk) 21 Development solenoid
11 Toner bottle drive motor (C) 22 PCU: Black/ Image transfer motor
Product Overview
41
