Ricoh MP C2504 User Manual

SC No. Type Error Name/Error Condition/Major Cause/Solution
SC541-02 A Non-contact Thermistor (Center) Disconnection
Above 3F6 is detected for 1 sec. continuously (NC sensor center:
detection & compensation NC sensor edge: detection & compensation).
Detection period: 0.1 sec, detection frequency: 10 times or more.
• Non-contact thermistor disconnection
• Connector disconnected
• Harness disconnection in the fusing unit
• Harness disconnection between the fusing unit and the BCU
• BCU defective
1. Reconnect the connectors (between the fusing unit and the BCU).
2. Replace the non-contact thermistor with the harness.
3. Replace the fusing unit.
4. Replace the harness between the fusing unit and the BCU.
5. Replace the BCU.
SC541-03 A Non-contact Thermistor (Center) short-circuit
Below AD value: 8 is detected for 1 sec. continuously.
Detection period: 0.1 sec, detection frequency: 10 times or more.
• Non-contact thermistor short-circuit
• Connector disconnected
• Harness disconnection in the fusing unit
• Harness disconnection between the fusing unit and the BCU
• BCU defective
1. Reconnect the connectors (between the fusing unit and the BCU).
2. Replace the non-contact thermistor with the harness.
3. Replace the fusing unit.
4. Replace the harness between the fusing unit and the BCU.
5. Replace the BCU.
Service Call 501-584
823

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
