SC No. Type Error Name/Error Condition/Major Cause/Solution

SC665-04 D IOB does not start up

The IOB does not start up when starting up, or recovery from energy

saver mode.

• Connector disconnected

• Harness disconnected

• The following board defects (Parts implementation defect, solder

scrap, implemented parts defect, etc.)

• BCU

• Imaging IOB

• Paper Transport IOB

1. Turn the main power OFF/ON.

2. Reconnect the following FFC;

• BCU - Imagine IOB

• Imaging IOB - Paper Transport IOB

3. Replace the following FFC;

• BCU - Imagine IOB

• Imaging IOB - Paper Transport IOB

4. Replace the BCU.

5. Replace the Imaging IOB.

6. Replace the Paper Transport IOB.

6. Troubleshooting

860
