39.4.18 Initialization
The initialization forces the CHnOI bit value to the channel (n) output when a one is
written to the INIT bit.
The initialization depends on COMP and DTEN bits. The following table shows the
values that channels (n) and (n+1) are forced by initialization when the COMP and
DTEN bits are zero.
Table 39-11. Initialization behavior when (COMP = 0 and DTEN = 0)
CH(n)OI CH(n+1)OI Channel (n) Output Channel (n+1) Output
0 0 is forced to zero is forced to zero
0 1 is forced to zero is forced to one
1 0 is forced to one is forced to zero
1 1 is forced to one is forced to one
The following table shows the values that channels (n) and (n+1) are forced by
initialization when (COMP = 1) or (DTEN = 1).
Table 39-12. Initialization behavior when (COMP = 1 or DTEN = 1)
CH(n)OI CH(n+1)OI Channel (n) Output Channel (n+1) Output
0 X is forced to zero is forced to one
1 X is forced to one is forced to zero
Note
The initialization feature must be used only with disabled FTM
counter. See the description of the CLKS field in the Status and
Control register.
39.4.19
Features priority
The following figure shows the priority of the features used at the generation of channels
(n) and (n+1) outputs signals.
Functional description
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
1000 NXP Semiconductors
