State Cycle Description
S0 All The read or write cycle is initiated. On the rising clock edge, FlexBus:
• Places a valid address on FB_ADn
• Asserts FB_TS/FB_ALE
• Drives FB_R/W high for a read and low for a write
S1 All FlexBus:
• Negates FB_TS/FB_ALE on the rising edge of FB_CLK
• Asserts FB_CSn
• Drives the data on FB_AD31– FB_ADX for writes
• Tristates FB_AD31– FB_ADX for reads
• Continues to drive the address on FB_AD pins that are unused for data
If the external memory or perihperal asserts FB_TA, then the process moves to S2. If FB_TA is not
asserted internally or externally, then S1 repeats.
Read The external memory or peripheral drives the data before the next rising edge of FB_CLK (the rising
edge that begins S2) with FB_TA asserted.
S2 All For internal termination, FlexBus negates FB_CSn and the transfer is complete. For external
termination, the external memory or peripheral negates FB_TA, and FlexBus negates FB_CSn after
the rising edge of FB_CLK at the end of S2.
Read FlexBus latches the data on the rising clock edge entering S2. The external memory or peripheral
can stop driving the data after this edge or continue to drive the data until the end of S3 or through
any additional address hold cycles.
S3 All FlexBus invalidates the address, data, and FB_R/W on the rising edge of FB_CLK at the beginning
of S3, terminating the transfer.
31.4.11 FlexBus Timing Examples
Note
The timing diagrams throughout this section use signal names
that may not be included on your particular device. Ignore these
extraneous signals.
Note
Throughout this section:
•
FB_D[X] indicates a 32-, 16-, or 8-bit wide data bus
•
FB_A[Y] indicates an address bus that can be 32, 24, or 16
bits wide.
31.4.11.1
Basic Read Bus Cycle
During a read cycle, the MCU receives data from memory or a peripheral device. The
following figure shows a read cycle flowchart.
