NXP Semiconductors K22F series User Manual

Peripherals
Transfers
AIPS-Lite
peripheral bridge
Transfers
Crossbar
switch
Figure 3-11. Peripheral bridge configuration
Table 3-17. Reference links to related information
Topic Related module Reference
Full description Peripheral bridge
(AIPS-Lite)
Peripheral bridge (AIPS-Lite)
System memory map System memory map
Clocking Clock Distribution
Crossbar switch Crossbar switch Crossbar switch
3.3.7.1 Number of peripheral bridges
This device contains one peripheral bridge.
3.3.7.2
Memory maps
The peripheral bridges are used to access the registers of most of the modules on this
device. See AIPS0 Memory Map for the memory slot assignment for each module.
3.3.8
DMA request multiplexer configuration
This section summarizes how the module has been configured in the chip. For a
comprehensive description of the module itself, see the module’s dedicated chapter.
System modules
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
74 NXP Semiconductors
