Table 13-46. Command bits:
Bit [31:
18]
[17] [16] [15] [14] [13] [12] [11] [10] [9] [8] [7] [6] [5] [4] [3] [2] [1] [0]
Command
Reserved
Reserved
Reserved
FlashReadResource
FlashReadOnce
FlashProgramOnce
Reserved
SetProperty
Reset
Call
Execute
Reserved
GetProperty
Reserved
FillMemory
WriteMemory
ReadMemory
FlashEraseRegion
FlashEraseAll
13.6 Kinetis Flashloader Status Error Codes
This section describes the status error codes that the Kinetis Flashloader returns to the
host.
Table 13-47. Kinetis Flashloader Status Error Codes, sorted by Value
Error Code Value Description
kStatus_Success 0 Operation succeeded without error.
kStatus_Fail 1 Operation failed with a generic error.
kStatus_ReadOnly 2 Requested value cannot be changed because it is
read-only.
kStatus_OutOfRange 3 Requested value is out of range.
kStatus_InvalidArgument 4 The requested command's argument is undefined.
kStatus_Timeout 5 A timeout occurred.
kStatus_FlashSizeError 100 Not used.
kStatus_FlashAlignmentError 101 Address or length does not meet required
alignment.
kStatus_FlashAddressError 102 Address or length is outside addressable memory.
kStatus_FlashAccessError 103 The FTFA_FSTAT[ACCERR] bit is set.
kStatus_FlashProtectionViolation 104 The FTFA_FSTAT[FPVIOL] bit is set.
kStatus_FlashCommandFailure 105 The FTFA_FSTAT[MGSTAT0] bit is set.
kStatus_FlashUnknownProperty 106 Unknown Flash property.
kStatus_FlashEraseKeyError 107 The key provided does not match the programmed
flash key.
kStatus_FlashRegionExecuteOnly 108 The area of flash is protected as execute only.
kStatus_I2C_SlaveTxUnderrun 200 I2C Slave TX Underrun error.
kStatus_I2C_SlaveRxOverrun 201 I2C Slave RX Overrun error.
Table continues on the next page...
Chapter 13 Kinetis Flashloader
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 339
