34.3.5 Compare Value Registers (ADCx_CVn)
The Compare Value Registers (CV1 and CV2) contain a compare value used to compare
the conversion result when the compare function is enabled, that is, SC2[ACFE]=1. This
register is formatted in the same way as the Rn registers in different modes of operation
for both bit position definition and value format using unsigned or sign-extended 2's
complement. Therefore, the compare function uses only the CVn fields that are related to
the ADC mode of operation.
The compare value 2 register (CV2) is used only when the compare range function is
enabled, that is, SC2[ACREN]=1.
Address:
Base address + 18h offset + (4d × i), where i=0d to 1d
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
0
CV
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
ADCx_CVn field descriptions
Field Description
31–16
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
CV Compare Value.
Memory map and register definitions
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
776 NXP Semiconductors
