3.2.5 JTAG Controller Configuration
This section summarizes how the module has been configured in the chip. For a
comprehensive description of the module itself, see the module’s dedicated chapter.
Signal
multiplexing
JTAG controller
cJTAG
Figure 3-5. JTAGC Controller configuration
Table 3-9. Reference links to related information
Topic Related module Reference
Full description JTAGC JTAGC
Signal multiplexing Port control Signal multiplexing
3.3 System modules
3.3.1 SIM Configuration
This section summarizes how the module has been configured in the chip. For a
comprehensive description of the module itself, see the module’s dedicated chapter.
Register
access
Peripheral
bridge
System integration
module (SIM)
Figure 3-6. SIM configuration
Table 3-10. Reference links to related information
Topic Related module Reference
Full description SIM
System memory map System memory map
Table continues on the next page...
Chapter 3 Chip Configuration
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 67
