Table 41-1. Modes of operation
Modes Description
Run The LPTMR operates normally.
Wait
The LPTMR continues to operate normally and
may be configured to exit the low-power mode
by generating an interrupt request.
Stop
The LPTMR continues to operate normally and
may be configured to exit the low-power mode
by generating an interrupt request.
Low-Leakage
The LPTMR continues to operate normally and
may be configured to exit the low-power mode
by generating an interrupt request.
Debug
The LPTMR operates normally in Pulse Counter
mode, but counter does not increment in Time
Counter mode.
41.2 LPTMR signal descriptions
Table 41-2. LPTMR signal descriptions
Signal I/O Description
LPTMR0_ALTn I Pulse Counter Input pin
41.2.1 Detailed signal descriptions
Table 41-3. LPTMR interface—detailed signal descriptions
Signal I/O Description
LPTMR_ALTn I Pulse Counter Input
The LPTMR can select one of the input pins to be used in Pulse Counter mode.
State meaning Assertion—If configured for pulse counter mode with
active-high input, then assertion causes the CNR to
increment.
Deassertion—If configured for pulse counter mode with
active-low input, then deassertion causes the CNR to
increment.
Timing Assertion or deassertion may occur at any time; input may
assert asynchronously to the bus clock.
41.3 Memory map and register definition
LPTMR signal descriptions
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
1042 NXP Semiconductors
