SIM_SOPT4 field descriptions (continued)
Field Description
Selects the source of FTM1 fault 0.
NOTE:
The pin source for fault 0 must be configured for the FTM module fault function through the
appropriate pin control register in the port control module.
0 FTM1_FLT0 pin
1 CMP0 out
3
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
2
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
1
FTM0FLT1
FTM0 Fault 1 Select
Selects the source of FTM0 fault 1.
NOTE:
The pin source for fault 1 must be configured for the FTM module fault function through the
appropriate pin control register in the port control module.
0 FTM0_FLT1 pin
1 CMP1 out
0
FTM0FLT0
FTM0 Fault 0 Select
Selects the source of FTM0 fault 0.
NOTE:
The pin source for fault 0 must be configured for the FTM module fault function through the
appropriate pin control register in the port control module.
0 FTM0_FLT0 pin
1 CMP0 out
12.2.5 System Options Register 5 (SIM_SOPT5)
Address: 4004_7000h base + 1010h offset = 4004_8010h
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
0
LPUART0RXS
RC
0 0
UART1RXSRC
UART1TXSRC
UART0RXSRC
UART0TXSRC
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SIM_SOPT5 field descriptions
Field Description
31–20
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
19–18
LPUART0RXSRC
LPUART0 receive data source select
Table continues on the next page...
Chapter 12 System Integration Module (SIM)
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 269
