NXP Semiconductors K22F series User Manual

Chapter 18
Miscellaneous Control Module (MCM)
18.1 Introduction
NOTE
For the chip-specific implementation details of this module's
instances, see the chip configuration information.
The Miscellaneous Control Module (MCM) provides a myriad of miscellaneous control
functions.
18.1.1
Features
The MCM includes the following features:
• Program-visible information on the platform configuration and revision
18.2
Memory map/register descriptions
The memory map and register descriptions below describe the registers using byte
addresses.
MCM memory map
Absolute
address
(hex)
Register name
Width
(in bits)
Access Reset value
Section/
page
E008_0008
Crossbar Switch (AXBS) Slave Configuration
(MCM_PLASC)
16 R 001Fh 18.2.1/400
E008_000A
Crossbar Switch (AXBS) Master Configuration
(MCM_PLAMC)
16 R 0017h 18.2.2/400
E008_000C Crossbar Switch (AXBS) Control Register (MCM_PLACR) 32 R/W 0000_0000h 18.2.3/401
Table continues on the next page...
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 399
