43.4.31 Clock recovery combined interrupt enable
(USBx_CLK_RECOVER_INT_EN)
Enables or masks the individual interrupt flags which are logically OR'ed together to
produce the combined interrupt indication on the USB_CLK_RECOVERY_INT bit in
the USB_USBTRC0 register if the indicated conditions have been detected in the USB
clock recovery algorithm operation.
Address:
4007_2000h base + 154h offset = 4007_2154h
Bit 7 6 5 4 3 2 1 0
Read
Reserved
OVF_
ERROR_EN
Reserved
Write
Reset
0 0 0 1 0 0 0 0
USBx_CLK_RECOVER_INT_EN field descriptions
Field Description
7–5
Reserved
This field is reserved.
Should always be written as 0.
4
OVF_ERROR_
EN
Determines whether OVF_ERROR condition signal is used in generation of USB_CLK_RECOVERY_INT.
0 The interrupt will be masked
1 The interrupt will be enabled (default)
Reserved This field is reserved.
Should always be written as 0.
43.4.32 Clock recovery separated interrupt status
(USBx_CLK_RECOVER_INT_STATUS)
A Write operation with value high at 1'b1 on any combination of individual bits will clear
those bits.
Address:
4007_2000h base + 15Ch offset = 4007_215Ch
Bit 7 6 5 4 3 2 1 0
Read Reserved
OVF_
ERROR
Reserved
Write w1c
w1c
w1c
Reset
0 0 0 0 0 0 0 0
