22.3.12 Set Enable Request Register (DMA_SERQ)
The SERQ provides a simple memory-mapped mechanism to set a given bit in the ERQ
to enable the DMA request for a given channel. The data value on a register write causes
the corresponding bit in the ERQ to be set. Setting the SAER bit provides a global set
function, forcing the entire contents of ERQ to be set. If the NOP bit is set, the command
is ignored. This allows you to write multiple-byte registers as a 32-bit word. Reads of this
register return all zeroes.
Address:
4000_8000h base + 1Bh offset = 4000_801Bh
Bit 7 6 5 4 3 2 1 0
Read 0 0 0
Write NOP SAER 0 SERQ
Reset
0 0 0 0 0 0 0 0
DMA_SERQ field descriptions
Field Description
7
NOP
No Op enable
0 Normal operation
1 No operation, ignore the other bits in this register
6
SAER
Set All Enable Requests
0 Set only the ERQ bit specified in the SERQ field
1 Set all bits in ERQ
5–4
Reserved
This field is reserved.
SERQ Set Enable Request
Sets the corresponding bit in ERQ.
