Table 2-9. Communication modules
Module Description
USB OTG (low-/full-speed) USB 2.0 compliant module with support for host, device, and On-The-Go modes.
Includes an on-chip transceiver for full and low speeds.
USB voltage regulator Up to 5 V regulator input typically provided by USB VBUS power with 3.3 V
regulated output that powers on-chip USB subsystem, capable of sourcing 120 mA
to external board components.
Serial peripheral interface (SPI) Synchronous serial bus for communication to an external device
Inter-integrated circuit (I2C) Allows communication between a number of devices. Also supports the System
Management Bus (SMBus) Specification, version 2.
Universal asynchronous receiver/
transmitters (UART)
Asynchronous serial bus communication interface with programmable 8- or 9-bit
data format and support of ISO 7816 smart card interface
I2S The I
2
S is a full-duplex, serial port that allows the chip to communicate with a
variety of serial devices, such as standard codecs, digital signal processors
(DSPs), microprocessors, peripherals, and audio codecs that implement the inter-
IC sound bus (I
2
S) and the Intel
®
AC97 standards
LPUART Low power UART module that retains functionality in stop modes.
2.2.9 Human-machine interfaces
The following human-machine interfaces (HMI) are available on this device:
Table 2-10. HMI modules
Module Description
General purpose input/output (GPIO) All general purpose input or output (GPIO) pins are capable of interrupt and DMA
request generation.
2.3 Orderable part numbers
The following table summarizes the part numbers of the devices covered by this
document.
Table 2-11. Orderable part numbers summary
Part number CPU
frequency
Pin count Package Program
flash
SRAM GPIO
MK22FN512VDC12 120 MHz 121 XFBGA 512 KB 128 KB 81
MK22FN512VLL12 120 MHz 100 LQFP 512 KB 128 KB 66
MK22FN512VLH12 120 MHz 64 LQFP 512 KB 128 KB 40
MK22FN512VMP12 120 MHz 64 MAPBGA 512 KB 128 KB 40
Table continues on the next page...
Chapter 2 Introduction
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 55
