25.3.9 MCG Auto Trim Compare Value High Register (MCG_ATCVH)
Address: 4006_4000h base + Ah offset = 4006_400Ah
Bit 7 6 5 4 3 2 1 0
Read
ATCVH
Write
Reset
0 0 0 0 0 0 0 0
MCG_ATCVH field descriptions
Field Description
ATCVH ATM Compare Value High
Values are used by Auto Trim Machine to compare and adjust Internal Reference trim values during ATM
SAR conversion.
25.3.10 MCG Auto Trim Compare Value Low Register (MCG_ATCVL)
Address: 4006_4000h base + Bh offset = 4006_400Bh
Bit 7 6 5 4 3 2 1 0
Read
ATCVL
Write
Reset
0 0 0 0 0 0 0 0
MCG_ATCVL field descriptions
Field Description
ATCVL ATM Compare Value Low
Values are used by Auto Trim Machine to compare and adjust Internal Reference trim values during ATM
SAR conversion.
25.3.11 MCG Control 7 Register (MCG_C7)
Address: 4006_4000h base + Ch offset = 4006_400Ch
Bit 7 6 5 4 3 2 1 0
Read 0 0
OSCSEL
Write
Reset
0 0 0 0 0 0 0 0
Memory Map/Register Definition
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
554 NXP Semiconductors
